Brand Name : | BLINCE |
Model Number : | PV2R hydraulic vane pump cartridge kits |
Certification : | ISO9001:2008 |
Price : | Negotiation |
Payment Terms : | T/T, Western Union |
Supply Ability : | 3000pcs/month |
Delivery Time : | 15-20days |
High Performance PVH1 PVH2 PVH3 Hidraulic Pump Part Repair Kits
PV2R single pump: PV2R1, PV2R2, PV2R3
PV2R double pump: PV2R12, PV2R13, PV2R23
They are the special model, lower noise and better quality than
Original PV2R vane pumps.
1. Same connecting dimension, but 4-8DB noise and better
performance(>85% effective than original pump.
2. Different dimension with Original PV2R parts, including the
cartridge kits and parts.
PV2R1, PV2R2, PV2R3, PV2R4, PV2R12, PV2R13, PV2R23, PV2R14, PV2R24,
PV2R34 are widely used in Heavy equipments, Mining machinery, Rubber & Plastic machinery, Shoes machinery, Die Casting Machinery,
Metallurgical machinery, Metal Cutting Machinery and other types of
hydraulic systems.
PV2R series of pumps are designed for low noise and high performance of the vane pump. The unique facilities, high precision machining and material selection, to ensure the high reliability, adaptability of the advantages, the most suitable for modern hydraulic system needs. In such as injection molding machine, pressure die casting machine, metal cutting machine tools, engineering machinery and other types of hydraulic systems are widely used.
Model | Theoretical displacement (mL/r) | Max pressure | Allowed driving speed (r /min) | |||||
Working oil of Petroleum series | Water-based synthetic hydraulic fluid | |||||||
Particular pressure oil | Anti-wear oil | Common oil | Anti-wear water-glyco | Sul phosuccinic Ester fatty of acid | Max | Mini | ||
PV2R1-6 PV2R1-8 PV2R1-10 PV2R1-12 PV2R1-14 PV2R1-17 PV2R1-19 PV2R1-23 PV2R1-25 PV2R1-28 PV2R1-31 | 6.1 8.1 10.2 12.3 14.0 16.3 18.3 22.5 25.1 27.6 30.6 | 21 | 17.5 | 16 | 16 | 16 | 1800 (1200) | 750 |
PV2R2-26 PV2R2-33 PV2R2-41 Pv2R2-47 PV2R2-53 PV2R2-59 PV2R2-65 PV2R2-75* | 25.4 32.2 40.5 46.2 52.3 58.2 64.1 74.5 | 21 | 17.5 | 14 | 16 | 14 | 1800 (1200) | 600 |
PV2R3-52 PV2R3-60 PV2R3-66 PV2R3-76 PV2R3-85 PV2R3-94 | 51.5 62.9 67.0 79.2 84.5 93.8 | 21 | 17.5 | 14 | 16 | 14 | 1800 (1200) | 600 |
PV2R3-116 PV2R3-125 PV2R3-136 PV2R3-153 | 113.2 122.8 135.8 152.8 | 17.5 | 16 | 14 | 1200 |
![]() |
