Eaton Char lynn H series OMPH BMPH 36cc 50cc Mini Hydraulic Motor ,
Hydraulic Torque Motor
Blince OMPH /BMPH series hydraulic torque motor are small volume,
economical type, which is designed with shaft distribution flow,
which adapt the Gerotor gear set design and provide compact volume,
high power and low weight.
It is equivalent with Eaton Char-lynn 101 H series gerotor
hydraulic motor.
Geometric displacement: 36cc, 50cc, 80cc, 100cc, 125cc, 160cc,
200cc, 250cc, 315cc, 400cc, 500cc.
Flange: two bolts/ four bolts rhomb flange, four bolts square
flange.
Shaft: 25 parallel key, 25.4 woodruff key, 25.4 splined tooth
Product advantage:
1.Products after phosphating treatment, not easy to rust
2.Used import bearing ensure that no laekage
3.Drain port flexible use in practice ,highly integrated
4.Threads of the mounting holes for conical teeth, sealed
performance is good
5.The in and out port are inclined,compact structure , convenient
operation
6.Our orbit motor has the function of automatic compensation torque
| type | OMP OMPH 36 | OMP OMPH 50 | OMP OMPH 80 | OMP OMPH 100 | OMP OMPH 125 | OMP OMPH 160 | OMP OMPH 200 | OMP OMPH 250 | OMP OMPH 315 | OMP OMPH 400 | OMP OMPH 500 |
| Geometric displacement | 36 | 51.7 | 77.7 | 96.2 | 120.2 | 157.2 | 194.5 | 240.3 | 314.5 | 389.5 | 486.5 |
| Max.speed.(rpm) | con. | 1500 | 1150 | 770 | 615 | 490 | 383 | 310 | 250 | 192 | 155 | 120 |
| int. | 1650 | 1450 | 960 | 770 | 615 | 475 | 385 | 310 | 240 | 190 | 150 |
| Max.torque(N.m | cont. | 55 | 100 | 146 | 182 | 236 | 302 | 360 | 383 | 375 | 360 | 385 |
| int. | 76 | 128 | 186 | 227 | 290 | 370 | 440 | 460 | 555 | 525 | 560 |
| Max.output(KW) | cont. | 8.0 | 10.0 | 10.0 | 11.0 | 10.0 | 10.0 | 10.0 | 8.5 | 7.0 | 6.0 | 5.0 |
| int | 11.5 | 12.0 | 12.0 | 13.0 | 12.0 | 12.0 | 12.0 | 10.5 | 8.5 | 7.0 | 6.0 |
Max.pressure Drop(Mpa) | cont. | 12.5 | 14 | 14 | 14 | 14 | 14 | 14 | 11 | 9 | 7 | 6 |
| int | 16.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 14 | 14 | 10.5 | 9 |
| Max.flow(L/min) | cont. | 55 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 |
| int. | 60 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 |
